Description
Overview…
WORKMATE MK2 version has no crossfader section and pan control but offers 3 adjustable stereo outputs instead. This is a great feature for it allows you to distribute the same stereo output signal to 3 different stereo zones. 4 volume/channel faders and the possibility of connecting 9 external devices, including 2 record players. Switching between these devices is easily done thru Select Switches on the front.
Key Features…
– Compact 2u low noise audio design
– 4 line control channels plus separate Mic section
– 2 stereo phono, 7 stereo Line and 3 Mic inputs
– 2-band equaliser per channel
– CUE per channel plus gain control
– 3 independent adjustable stereo outputs
– Stereo Master audio out on both RCA and balanced XLR
– Balanced stereo Booth output on 6.3MM connectors
– Stereo Zone output on RCA connectors
– Smart Media Player
– Select play from USB, SD (both max 32GB) and thru Bluetooth
– Plays both WAV and MP3 files
– All, Single, Repeat and Random Play
Tech Spec…
– Power Consumption: 12W typical, 21W w/ full headphone output.
– Power Supply: Integrated transformer AC 230V-50Hz.
– Weight: 3 kg
– Mic: 600 ohm input impedance unbalanced
– Line: 9V rms max
– Dimensions: 19\” 2he Rack mount, Front 483x88mm Rear
– Line/Aux: 10Kohm input impedance
– Package Dimension: 555 x 325 x 470 mm
– Operating Temperature: 5 to 35 deg. CC
– Humidity: 25 to 85%.(Non-condensing)
– Storage Temperature: -20 to 60 deg. C
