Clever Acoustics ZM 8 BW Wall Plate

£79.00 Ex VAT: £65.83

In stock

SKU: CRAM19A Category:

Description

– 3 year warranty
– Zone LED indicator with up/down buttons
– Volume controls provided
– DC 24V power supply from controller
– Metal back box supplied
– Remote line via phono and microphone via XLR inputs with gain controls
– Source selection and volume control
– Line, mic and source selection are sent using a single CAT5e cable
– Only for use with the ZM 8 Zone Mixer (CRAM19)

Overview…
Dedicated wall plate for the ZM 8 Zone Mixer. Installation of the plates requires simple, easy connection via standard RJ45 terminated CAT5e cable.

Tech Spec…
– Serial communication speed: 4800bps
– Communication port: RJ45
– Communication protocol: RS485
– Serial communication distance: 1km maximum
– MIC input sensitivity: 5mV/600Ω, Phantom power: +12V 350mV/10kΩ
– AUX input sensitivity: 350mV/10kΩ
– Audio output: 0dB/600Ω
– Frequency response: 50Hz-18kHz (±1dB)
– S/N ratio: MIC: >65dB, AUX: >75dB
– THD: <0.1% @ 1kHz
– Power consumption: 5W
– Power supply: DC 24V
– Dimensions (H x W x D): 86 x 86 x 48mm
– Weight: 70g

Additional information

Weight 0.7 kg
Dimensions 1331809.3 cm
