Product Overview…
100V line mixer-amplifier with built-in multi-format media player. 5 input channels include a balanced XLR microphone input with switchable phantom power and Vox override, 2 mic/line jack inputs and 2 RCA line inputs.
A powerful class AB amplifier section is paired with a digital switch-mode power supply and 100V transformer for reliable power delivery from an energy efficient power section.
A built-in CD player provides audio playback alongside a USB/SD media player with an integral DAB+ and FM radio tuner. Additional Bluetooth® receiver enables pairing to a smartphone for wireless playback of stored tracks.
Bass & Treble EQ and Master volume control the overall output, which can power either low impedance or 100V line speakers.
A comprehensive solution for commercial sound installations.
Tech Spec…
- Power supply-170-264Vac, 50Hz (IEC)
- Fuse-T3.15A
- DC power-24Vdc (screw terminals)
- Power : rms-120Wrms (100V or 4 Ohms)
- Inputs-Mic XLR, 2 x mic/line jack, 2 x RCA line
- Input sensitivity : mic 1 (balanced)-53dBV
- Input impedance : mic 15k Ohms
- Input sensitivity : line (unbalanced)-15dBV (-18.5dBV line 5)
- Input impedance : inputs 2-51k Ohms
- Line output-RCA
- Speaker outputs-100V / 4-16 Ohms / COM terminals
- Bluetooth version-5.0
- Controls-Mic1, mic/line2+3, line4+5 (USB), bass, treble, master volume
- Equaliser : bass100Hz ±10dB
- Equaliser : treble10kHz ±10dB
- Rear panel switches-Mic/Line (2 + 3), Phantom, Vox
- Phantom power+20V (MIC 1 input)
- THD-<1.0%
- Dimensions-433 x 320 x 89mm
- Weight-7kg
