Description
● 5 channel 19″ rack-mountable mixer amplifier, tailored to commercial sound installations
● DAB+/FM radio tuner
● Bluetooth receiver with unique serial ID
● USB/SD audio player
● Ideal for Gyms, Tannoy Systems, Sports Centres, Cafes, Reception areas, Pubs and general PA requirements
Overview…
RM240D 100V Mixer Amplifier with DAB+, BT, USB/SD…
5-channel 19″ rack-mountable mixer-amplifier, tailored to commercial sound installations to power 100V line speakers or standard speakers down to a 4 Ohm load. Input options include XLR (with switchable phantom power), mic/line jack, and RCA line. Features an inbuilt DAB+/FM radio tuner, front-mounted SD/USB ports, and Bluetooth® connectivity, all controlled via an integrated media player for hassle-free playback. A switchable ‘voiceover’ feature automatically lowers the background music volume when a signal is detected via mic input 1 and rear panel 24V contacts can mute all except mic input 1 when triggered. Outputs on screw terminals are via 4 switchable zones with a separate “always on” output for priority alert speakers.
Key Features…
– DAB+/FM radio tuner
– Bluetooth receiver with unique serial ID
– USB/SD audio player
– 4 switchable 100V outputs and 1 unswitched output
– Optional 4-16 Ohm output
– XLR input with switchable +20V phantom power
– 2 x mic/line inputs, 2 x RCA line inputs, 1 x RCA line output
– Switchable VOX voiceover feature
– 2U 19″ rack mountable (rack ears supplied)
– 24V emergency mute contacts
– Mains 230Vac or 24Vdc power option
Tech Spec…
– Power supply: 170-264Vac, 50Hz (IEC)
– DC power: 24Vdc (screw terminals)
– Inputs: Mic XLR, 2 x mic/line jack, 2 x RCA line
– Input sensitivity mic 1: (balanced)-53dBV
– Input impedance: mic 15k Ohms
– Input sensitivity line: (unbalanced)-15dBV (-18.5dBV line 5)
– Input impedance: inputs 2-51k Ohms
– Line output: RCA
– Speaker outputs: 4 switched + 1 non-switched 100V / 4-16 Ohms / COM
– Controls: Mic1, mic/line2+3, line4+5, bass, treble, master volume
– Equaliser bass: 100Hz ±10dB
– Equaliser treble: 10kHz ±10dB
– Rear panel switches: Phantom, Vox, Mic/Line (2 + 3)
– Phantom power: +20V (mic 1 XLR, switchable)
– Audio source: DAB+/FM tuner, USB/SD player, Bluetooth receiver
– Emergency control: 24V contacts – mute all except Mic.1 when triggered
– Bluetooth version: 5.0
– THD: <1.0%
– Output Power RMS: 240W
– Fuse: T5A
– Dimensions: 433 x 320 x 88mm
– Weight: 7.37kg
