Description
Rapid QB1 HEX is a portable battery powered uplighter outputting ultra-smooth colours from rich saturated hues to subtle pastel shades. The compact and robust housing design makes this fixture extremely portable and easily concealable. The internal lithium battery has autonomy of up to 18 hours in single colour mode and up to 5.5 hours of colour fading and chases, while the charging time is only 5 hours. The light source is composed of 4 x 12W high-power RGBWAUV LEDs and the extractable foot allows you to adjust the tilt angle. The on-board wireless transceiver makes for a truly cable free operation and is W-DMX compatible.
Features
4 x 12W sixcolour LEDs (RGBWAUV)
Beam angle: 25 Degree (field angle: 45 Degree)
1,230 Lux @ 2m
1.2kHz refresh rate
DMX channels: 6/8 or 12 selectable
Wireless control (WDMX Sweden compatible transceiver)
Static colour
colour change
colour fade
auto
sound active and master/slave modes
0100% dimming and variable strobe
M10 rigging point for clamp
Adjustable foot support for angled floor standing applications (up to 25 Degree)
Carry handle for transportation
Safety bond/security chain point
4 push button menu with LED display
Rechargeable battery for wireless applications
Maximum run time: up to 18 hours (single colour)
5.5 hours (colour change/fade)
3 hours (full on)
Charging time: 5 hours (max.)
IEC power input/output
3Pin XLR input/output
Convection cooled
Supplied with IR remote
Technical Specifications
Power consumption: 55W
Power supply: 100~240V
50/60Hz
Fuse: F3.15A 250V
Battery: 14.8V 5200mAh
Battery fuse: F5A 250V
Dimensions: 204 x 138 x 144mm
Weight: 3kg
Dimensions
Height: 27.5cm
Width: 19.0cm
Depth: 18.0cm
Weight
3.8kg
