Description
Multi-purpose, four universe DMX processor featuring three modes of operation: Art-NetT to DMX node, four universe DMX to Art-NetT processor or DMX splitter/buffer.
Features
ArtNetT input/throug via etherCONT RJ45
2048 channels
4 push button menu with LCD display
6 user presets
10/100M LAN interface
Supports TCP/IP protocol
Manual IP address selection
Four DMX512 outputs
four DMX inputs via 5Pin XLR
RDM Support
Electronically isolated inputs and outputs
IEC power input
19”/1U rack mountable
Technical Specifications
Power supply: 100~240V
50/60Hz
Dimensions: 45 x 484 x 152mm
Weight: 1.98kg
Dimensions
Height: 14.3cm
Width: 24.0cm
Depth: 53.7cm
Weight
2.6kg
